Prefixes and Suffixes
Common prefixes and suffixes used on Jay R. Smith Mfg. Co. products are listed below. Included are prefixes and suffixes for outlet types, drains and fixture supports.
| PREFIX | OUTLET TYPE |
|---|
| BW |
Butt Weld Outlet |
| C |
Inside Caulk Outlet |
| L |
Speedi-Set Outlet |
| LXH |
Speedi-Set Outlet Extra Heavy |
| S |
Spigot Outlet |
| T |
Female Threaded Outlet (unless specifically stated as male) |
| *Y |
NO-HUB Outlet |
*Integral NO-HUB connection. If not available with integral NO-HUB connection, specify threaded outlet with Fig. 2646Y No- Hub adaptor or an inside caulk outlet with Fig. 9502 Speedi Seal Gasket.
Suffix Y in Cleanout Section denotes carpet maker.
Suffix Y in 2005/2010 Series only denotes overflow variation with standpipe strainer.
| PREFIX | DRAINS |
|---|
| DX |
Wide Flange |
| SUFFIX | DRAINS |
|---|
| A |
Aluminum |
| AA |
Aluminum Body and Collar |
| AB |
Aluminum Bucket |
| AC |
Aluminum Cover |
| ARI |
Acid Resistant Coating Inside |
| ARIO |
Acid Resistant Coating Inside and Outside |
| B |
Sediment Bucket |
| BB |
Bronze Body |
| BFV |
Ball Float Backwater Valve |
| BS |
Bucket With Mesh Screen |
| C |
Flashing Clamp |
| CP |
Chrome Plated |
| D |
Dome Grate |
| E |
Extension |
| F |
Flange |
| FP |
Frost Proof Bucket |
| G |
Galvanized |
| H |
Hinged Grate |
| H |
Vacuum Breaker |
| HC1 |
1" Hose Connection |
| HP |
Heel Proof Grate |
| LB |
Less Bucket |
| LD |
Less Dome |
| LG |
Less Grate |
| M |
Ductile Iron Grate |
| MBG |
Ductile Iron Bucket and Grate |
| N |
1/8" Drain Hole In Box |
| NB |
Polished Nickel Bronze |
| NH |
High Auxiliary Inlet |
| NL |
Low Auxiliary Inlet |
| P050; P075 |
Trap Primer Connection |
| PB |
Polished Bronze |
| R |
Sump Receiver |
| RB |
Rough Bronze |
| S |
Square Top |
| SB |
Statuary Bronze |
| SBP |
Solid Bottom Ported Bucket |
| SEC |
Secured Grate |
| SF |
Satin Finish |
| SG |
Slotted Grate |
| SH |
Securing Holes |
| U |
Vandal Proof Top |
| V |
Backwater Valve |
| WH |
Wheel Handle |
| W |
With Seepage Holes |
| XP; XPB; XPP; XPSS |
Closure Plug |
| Z |
Enzyme Opening |
| SUFFIX | FIXTURE SUPPORTS |
|---|
| B |
Threaded Connection |
| C |
Copper Sweat |
| D |
Double |
| E |
Escutcheon |
| G |
Galvanized Adjustable |
| | Support |
|---|
| KF |
Knee Action Valve (Fixture Mtd.) |
| KW |
Knee Action Valve (Wall Mtd.) |
| L |
Left Hand |
| N |
Auxiliary Inlet |
| R |
Right Hand |
| U |
Vandal Proof Trim |
| Z |
For Narrow Wall Use |
| M11 |
Floor to Ceiling Uprights |
| M12 |
Flush Valve Supply Support |
| M13 |
Tiling Frame |
| M17 |
Water Closet Setting Gauge |
| M24 |
Ext. Adaptor for Concealed Arms |
| M30 |
Special Offset Arm Application |
| M31 |
Heavy Duty Rectangular Steel Uprights |
| M32 |
Round Steel Uprights |
| M40 |
Wide Pipe Chase |
| M50 |
High Set Legs |
| M51 |
Anchor Foot Assembly |
| M54 |
Face Plate with Side Leg Assembly |
| M58 |
Face Plate with "O" Ring Seal and Adjustable ABS Nipple |
| M73 |
Rear Outlet Closet Connection (9") |
| M74 |
Rear Outlet Closet Connection (6") |
| 2 |
Type 2 Coupling |
| 27 |
Extended Arms for Handicapped Lavatory |
| 2M |
Type 2M Coupling |
| 95 |
Test Cap Assy. (C.I. Nipples Only) |
