Model 4180-4194
Terrazo and Similar Tile Floor Cleanouts with Square Nickel Bronze Tops and Tile Recess
This labor saving cleanout uses our Twis-to-Floor® adjustment technology to level the top with adjacent surfaces after terrazzo and similar poured floors are installed. Its 5-3/4” (145) diam. nickel bronze top is recessed 1/2” (13) and locks in the poured flooring material for an unobtrusive appearance. Constructed of Duco coated cast iron, this cleanout is designed to support foot and medium load wheeled traffic.
Downloads
Resource Type | Title | Description | Answers | File Size | Action | |
|---|---|---|---|---|---|---|
 | | Submittal 4180 Cleanout | 1 MB | |||
 | | DWG 4180 Cleanout | 0 | 77 KB | ||
| | DWG 4185 Cleanout | 0 | 91 KB | ||
| | DWG 4191 Cleanout | 0 | 110 KB | ||
| | Submittal 4185 Cleanout | 0 | 944 KB | ||
| | Submittal 4191 Cleanout | 0 | 734 KB | ||
| | Specifications for Cleanouts | 0 | 217 KB | ||
| | Who we are, Our History, Morris Group International Today | 0 | 7 MB | ||
| | MGI Brands Flyer (pdf) | 0 | 718 KB | ||
| | Flyer for Cleanouts | 0 | 847 KB | ||
 | | 0 | 38 KB | |||
| | 0 | 37 KB | |||
| | 0 | 23 KB | |||
| | Technical Data for Cleanouts | 0 | 906 KB | ||
| | Order Guidelines for Cleanouts | 0 | 120 KB | ||
| | Parts Order Guide for Cleanouts | 0 | 910 KB | ||
| | Quote Worksheet Smith Drainage Systems | 0 | 39 KB |
Specifications
| Variations | Flashing Flange -F, Flashing Flange and Clamp -F-C, Vandal Proof -U - Top, (2) 3/8” (10) Tappings -TAP |
| Optional Materials | Galvanized Cast Iron -G, Polished Bronze Top - PB |
| Product Type | Cleanout |
